Assemble Zone [64] Galaxy Flex Installer Manual
166
Assemble Zone [64]
The Assemble Zone option allows 2 zone functions to be customised to the user’s
requirements; these are the 1 Custom-A and 2 Custom-B zones. Once a custom zone
function has been assembled, it is assigned to zones using Program Zones [52].
Programming a Custom Zone
The flexibility of this menu option allows for an extensive range of possibilities. It is
therefore important that the engineer is fully aware of the system and has a clear picture of
what is required of the new zone function.
The procedure for assembling a custom zone has 4 stages:
Outputs
Status
Setting
Log
Assemble Zone Menu
64 = Assemble Zone (select of two custom zones)
1 = Outputs (Select output type, then press # to toggle between Disabled,
Set, Unset, Set/Unset. Press esc
escesc
esc to save programming)
2 = Status
1 = Unset (Press # to toggle between Disabled and Alarm)
2 = Entry/Exit (Press # to toggle between Disabled and Alarm)
3 = Part Set (Press # to toggle between Disabled and Alarm)
4 = Full Set (Press # to toggle between Disabled and Alarm)
3 = Setting
1 = Begin Set (Press # to toggle between Disabled and Enabled)
2 = Begin Entry (Press # to toggle between Disabled and Enabled)
3 = Sets System (Press # to toggle between Disabled and Enabled)
4 = Log (Press # to toggle between Disabled, Entry/Exit, 24 Hours, Alarms)
Outputs [64.1]
Any of the available output types can be assigned to the custom zone. On selecting this
attribute the 01=BELLS output type is displayed along with its status. The default status is
disabled. The status indicates the conditions under which the custom zone activates the
output. To assign the output type status press the # key, this toggles between each of the
status settings:
1=Disabled the output is not activated by the custom zone.
2=Set the output is activated by the custom zone only when the system is set.
3=Unset the output is activated by the custom zone only when the system is unset.
