Secure tampers Galaxy Flex Installer Manual
20
Secure tampers
1. If an external siren/bell/warning device is fitted, connect the tamper return line from the
device to the T terminal.
2. If an external siren/bell/warning device is not fitted, connect the T terminal directly to
the 0 V terminal.
3. Replace and secure the panel cover.
Learn wireless detectors
Learn new wireless detectors as follows:
1. On the keypad select RF Zones (52 ent 2 ent).
2. Scroll to an empty zone, and then press ent.
3. Press 11 ent 1 ent.
4. Press
to enter Self-Learn mode.
5. Insert the battery in the detector and activate the tamper switch. The serial number of
the detector is recorded and displayed for 2 seconds.
If the signal strength is less than 3/10, the message 'signal strength too low' is
displayed for 2 seconds.
If there is already an identical serial number on the system, the message 'zone
already allocated' is displayed followed by the zone details. Either accept the
situation and learn the next wireless device from step 5, or delete the serial number
from this zone and repeat the learn procedure.
If the detector is a multi-loop device, select the 2=Loop No menu option, and then
enter a loop number (1 – 6, or 0 for a single input device).
6. If the RF device does not learn, remove the battery, short circuit the battery terminals,
replace the battery and repeat the above procedure.
7. Repeat the procedure from step 2 for each wireless device.
Additional programming
Use this section as a quick reference to some of the functions you may wish to program or
modify.
Parameters (51 ent)
Entry Time (05 ent) – defines the user unsetting time
Exit Time (
04 ent) – defines user exit time before system set
Bell Time (01 ent) – bell sounding time (default = 15 mins)
Bell Delay (02 ent) – delay bell activation for up to 20 mins
