Model IFP-2100/ECS Installation Manual LS10143-001SK-E
8-7
8.2.3 Event Mapping
There are 11 types of Zone events, 14 types of Panel events, and 40 types of Site events that can be mapped (see
Table 8-1). For each event type, you can activate the output groups with specific output patterns. Mapping
examples are shown in Figure 8-4, Figure 8-5, & Figure 8-6.
Table 8-1: Event Types
System Zone Panel Site
Fire
Manual Pull Alarm System Aux 1 Alarm Fire Drill
Water Flow Alarm System Aux 2 Alarm General Fire Alarm
Detector Alarm
(heat or smoke detectors)
General Fire Supervisory
Zone Aux 1 Alarm General Fire Pre-Alarm
Zone Aux 2 Alarm
Interlock Alert
Interlock Release
Pre-Alarm
Fire Supervisory
Status Point
CO Alarm
CO Supervisory
Emergency
LOC ECS 1-8 Alarm
General ECS Alarm
General ECS Supervisory
Point ECS 1-8 Alarm
Advisory
Trouble SBUS Expander Trouble General Trouble
Status Point Active SBUS Class A Trouble Site Silenced
SLC Loop Trouble Voice Aux In 1-8 Alarm
AC Loss Trouble F1 Key Active
Battery Trouble F2 Key Active
Ground Fault Trouble F3 Key Active
Phone Line Trouble F4 Key Active
Reporting Account Trouble Voice Aux in 1-2
Printer Trouble System Mic Active
Aux Power Trouble Background Music
System Switch Trouble
Output Group Trouble
