Honeywell IFP-2100ECS User Manual

Model IFP-2100/ECS Installation Manual LS10143-001SK-E
10-17
Release Alarm” outputs will activate. (Also refer to Table 10-4).
10.7.2 Double Interlock Zone Releasing
A Double Interlock Zone uses a minimum of two addressable detectors, a designated manual release switch, and
an interlock switch input. An interlock switch is typically a dry-contact pressure switch and will be referred to as
an interlock/pressure switch in this document.
Conditions Required for a Interlock Release Alert Output Activation
If any single addressable detector is activated, the “Interlock Release Alert” output will activate. This alerts the
user that the initial stages required for a release condition are present. (Also refer to Table 10-5).
Conditions Required for a Detector Alarm Output Activation
If two addressable detectors, a manual release switch is activated, or an interlock switch is active, the “Interlock
Release Alert”, and “Detector Alarm” outputs will activate.
Conditions Required for a Interlock Release Alarm Output Activation
Any release requires the activation of an interlock switch, and either a manual release switch or 2 activated
addressable detectors. When these conditions are met, the “Interlock Release Alarm” and “Detector Alarm”
outputs will activate, and the “Interlock Release Alert” outputs will deactivate.
Table 10-4: Single Interlock Zone Operation
Inputs Output Results
1st Addressable Detector
X X X X
2nd Addressable Detector
X X X X
Manual Release Station
X X X X
Normal
Interlock Release Alert Interlock Release Alert
Interlock Release Alarm
and Detector Alarm
Interlock Release Alarm
and Detector Alarm
Interlock Release Alarm
and Detector Alarm
Interlock Release Alarm
and Detector Alarm
Interlock Release Alarm
and Detector Alarm
Important!
Only addressable detectors can be used. No conventional detectors can be used.
Each Double Interlock Zone input requires at least one Interlock/pressure switch and at least one manual release switch.
Table 10-5 Double Interlock Zone Operation
Inputs Output Results
1st Addressable
Detector
X X X X X X X X
2nd Addressable
Detector
X X X X X X X X
