Model IFP-2100/ECS Installation Manual LS10143-001SK-E
3-15
1. The FACP can only support 5 devices w/LED’s on. This current draw has been added to the panels alarm current.
2. If using door holders, you do not need to consider door holder current for alarm/battery standby, because power is removed during
that time. However, during normal operation, door holders draw current and must be included in the 6.0A total current that can be
drawn from the panel.
3. Use next size battery with capacity greater than required.
4. SK-BEAM-T draws a maximum of 500mA from Auxiliary power only when the test feature is used. this should be considered when
determining auxiliary power capacity but not calculated into current requirements for day to day operation.
5. The SK-DUCT housing contains a vacant mount for a SK-RELAY (sold separately). Current draw for the SK-RELAY is calculated
by increasing the SK-RELAY row of the calculation sheet by one for each SK-RELAY used with a SK-DUCT.
3.7.4 Current Draw Worksheet for SD SLC Devices
Use Table 3-4 to determine current requirements during alarm/battery standby operation when SD SLC devices
are installed. You can install up to 127 SD devices per loop (2032 max per panel). Copy this section if additional
space is required.
1
Total ampere hours
required
Table 3-4: Current Draw Worksheet for SD SLC Devices
Device # of Devices Current per Device
Standby
Current
Alarm Current
For each device use this formula: This column X This column = Current per number of devices.
Fire Panel (Battery current draw) 1
Standby: 230 mA 230 mA
Alarm: 415 mA 415 mA
SD500-AIM
Standby/Alarm: .55 mA
6
mA mA
SD500-MIM mA mA
SD500-PS mA mA
SD500-ARM mA mA
SD505-HEAT mA mA
SD505-PHOTO mA mA
SD500-ANM
Aux. Pwr
Standby: 8 mA mA
Alarm: 60 mA mA
SLC Standby/Alarm: .55 mA mA mA
SD500-SDM
SLC Standby/Alarm: .55 mA mA mA
Aux. Pwr
Standby: 20 mA mA
Alarm: 106 mA mA
SLC Accessory Base
SD505-6RB Standby/Alram: .082 mA mA mA
SD505-6SB
Aux. Pwr
Standby: 1 mA mA
Alarm: 32 mA mA
SLC Standby/Alarm: .082 mA mA mA
Table 3-3 Current Draw Worksheet for SK SLC Devices
Device # of Devices Current per Device
Standby
Current
Alarm
Current
