LS10143-001SK-E Programming
9-30
6. Press ENTER
to accept the displayed SLC family.
Note: When changing SLC type the following message will appear:
Figure 9-15 SLC family change
Note: Message when changing SLC family from IDP or SK to SD: Changing to this SLC family will remove all
external 6815’s.
Note: Message when changing from SD to IDP or SK SLC family will remove all 5815XL’s on the system.
9.7 JumpStart
®
AutoProgramming
To run JumpStart:
1. Enter the installer code. The panel will automatically go to the main menu.
2. Select 7 for Panel Programming.
3. Select 6 for JumpStart
®
.
4. Press ENTER to accept the warning screen.
5. Follow the remaining on screen instructions.
6. Press ENTER to confirm. See Section 8.1.3.
9.8 Restore Defaults
This option allows you to restore the panel back to factory defaults. All programming will be lost.
1. Enter the installer code. The panel will automatically go to the main menu.
2. Select 7 for Panel Programming.
3. Select 7 for Restore Defaults.
4. Press the up or down arrow key to select YES or NO from the warning screen. Then press ENTER.
9.9 Voice Options
Through this programming menu you can modify the messages programmed into an VCM. You can also modify
other voice settings.
IMPORTANT!
JumpStart AutoProgramming is used to auto learn the system hardware after devices have been added or removed from the
system. Hardware devices which remain the same between repeat JumpStarts will retain any customized text or options
associated with the device. It is best to carefully consider the network ID setting for each panel before the first JumpStart
AutoProgramming is performed. Once this is done the panel must be defaulted back to factory defaults if the network ID
settings need to change.
