Honeywell IFP-2100ECS User Manual

LS10143-001SK-E Programming
9-20
Table 9-7 Choices for Point Programming Modules
Choices Type Selections
Function Selections
for each Type
Comments
5880 (output)
UNUSED
NOTIF
(outputs pt 1-40)
NOTIF OUTPUT
CONTROL CIRCUIT
5880 (input 41-48)
SWITCH MANUAL PULL Refer to comments column of
Table 9-4 for description of these
options.
Latch or Non-latching feature only
appears for WATERFLOW, FIRE
SUPERVISORY, FIRE TAMPER, ZONE
AUX1, ZONE AUX2, SYSTEM AUX1,
SYSTEM AUX2, ECS INPUT, ECS
TAMPER, and ECS SUPERVISORY.
WATERFLOW
FIRE SUPERVISORY
FIRE TAMPER
DETECTOR
FIRE DRILL
SILENCE
RESET
P.A.S. ACK
ZONE AUX1
ZONE AUX2
SYSTEM AUX1
SYSTEM AUX2
MANUAL RELEASE
INTERLOCK
STATUS POINT
ECS INPUT User also has ECS Event Number 1-8
option for ECS INPUT, ECS TAMPER,
and ECS SUPERVISORY functions in
both 5880 and ECS-VCM/ECS-RVM
choices.
Only available when an ECS-VCM is
installed in the system to the ECS-
VCM/ECS-RVM choice part.
ECS TAMPER
ECS SUPERVISORY
5496
UNUSED
B NOTIF NOTIF OUTPUT supervised
not supervised
CONTROL CIRCUIT
A NOTIF NOTIF OUTPUT
CONTROL CIRCUIT
AUX_PWR CONSTANT
AUX RESET
AUX DOOR
AUX SYNC Can not be supervised
5865
UNUSED
NOTIF NOTIF OUTPUT
CONTROL CIRCUIT
ECS-AMP
UNUSED
NOTIF
