Model IFP-2100/ECS Installation Manual LS10143-001SK-E
1-3
1.1.5 Terms Used in this Manual
The following terminology is used with the above mentioned control panels:
1.2 Compatible Products
Table 1-1 lists the products available for use with the IFP-2100/ECS.
Term Description
SLC Signaling line circuit
Module The term module is used for all hardware devices except for SLC addressable devices and
notification appliances. This includes the IFP-2100/ECS/RFP-2100 panels itself and the built-in
power supply. It also refers to any (optional) 5815XL or 6815 SLC expansion modules.
Input Point An addressable sensing device, such as a smoke, heat detector or a contact monitor device
Input Zone A protected area made up of input points
Output Point
(or “Output Circuit”)
A notification point or circuit for notification appliances. Relay circuits and auxiliary power
circuits are also considered output points
Group (or “Output Group” or
OPG)
A group of output points. Operating characteristics are common to all output points in a group
Mapping Mapping is the process of specifying which outputs are activated when certain events occur in
the system. Section 8.2 explains mapping in detail
Networking Up to 32 panels can be networked.
Network System Consist of any combination of 32 panels of these model numbers: IFP-75, IFP-300, IFP-
300ECS, IFP-2100, IFP-2100ECS, RFP-2100, IFP-2000, or IFP-2000ECS
ECS Emergency Communication System
SWIFT Smart Wireless Integrated Fire Technology
Table 1-1: IFP-2100/ECS Compatible Products
Type of Device Model Description
IDP Addressable
SLC Devices
See Section 7.1 for a list of compatible devices
SK Addressable
SLC Devices
See Section 7.2 for a list of compatible devices
SD Addressable
SLC Devices
See Section 7.3 for a list of compatible devices
SWIFT Wireless
SLC Devices
See Section 7.4 for a list of compatible devices
Other Modules
5824 Serial/Parallel Printer
Interface Module
Allows a printer to be attached for the system for on-site logging. Four
maximum per system.
5815XL (Rev H or above)
SLC Expander
Each 5815XL allows up to 127 SD devices to be added to the system. The
number of 5815XLs that can be added to the system is limited only by the
maximum number of SBUS devices. However the maximum SD point
count is limited to 2032 per panel. 5815XL will only support SD protocol
devices
