133
Page 133
Mini-AT User Guide
Item
No. Item Name Description
————————————————————————————————————————
399 RATE LOW LIMIT Limit for Low Flow Rate Alarm (item 461).
Default = 0.0
400 INSTRUMENT CONFIG Item to enable or disable Plog Pressure Logging.
Select: 2 - PLog off Default
6 - PLog on
401 PLOG SAMPLE INTVL. Selection for the number of seconds between timed wakeups to
obtain PLog pressure readings.
Select: 0 - 60 Seconds
1 - 30 Seconds
2 - 15 Seconds
3 - 10 Seconds
4 - 5 Seconds
407 PLOG XDUCER TYPE Item to select if PLog transducer is gauge or absolute type.
Select: 0 - Gauge Default
1 - Absolute
408 PLOG PRESSURE UNITS Code (0-9) that selects the unit of measurement for PLog Gas
Pressure (420) and other PLog pressure related items.
Select: 0 - PSIG--Default 5 - mBAR
1 - PSIA 6 - KGcm2
2 - kPa 7 - inWC
3 - mPa 8 - inHg
4 - BAR 9 - mmHg
409 PLOG PRESS DISP RES Code (0-4) that selects the number of decimal positions to the
right of decimal point for item 420 and other PLog pressure
related items.
Select: 0 - x x x x x x x x
1 - x x x x x x x.x
2 - x x x x x x.x x
3 - x x x x x.x x x
4 - x x x x.x x x x
410 PLOG CAL DATE Date of the most recent change to PLog CAL ZERO (Item
414). The date is automatically inserted into item 410 when
exiting the PLog CAL ZERO calibration function.
Default = 01-01-98
411 PLOG XDUCER SER# Serial number of the PLog pressure transducer (printed on the
transducer label), manually inserted at the factory. Note:
forcing Factory Defaults will
not change the value of this item.
Default = 00000000
