Honeywell Mini-AT User Manual

43
Page 43
Mini-AT User Guide
Selected
Volume Units
Item 90, 91 & 92
Units
CuFt
CuFt
X
10
CuFt
X
100
CuFt
X
1000
CuFt
X
10,000
m3
X
0.1
m3
X
1
m3
X
10
m3
X
100
m3
X
1000
CuFt
2.00000 0.20000 0.02000 0.00200 0.00020 0.56634 0.05663 ----- ----- -----
CuFt x 10
20.00000 2.00000 0.20000 0.02000 0.00200 5.66340 0.56634 0.05663 ----- -----
CuFt x 100
(CCF) ----- 20.00000 2.00000 0.20000 0.02000 56.63400 5.66340 0.56634 0.05663 -----
CuFt x 1,000
(MCF) ----- ----- 20.00000 2.00000 0.20000 ----- 56.63400 5.66340 0.56634 0.05663
CuFt x 10,000
----- ----- ----- 20.00000 2.00000 ----- ----- 56.63400 5.66340 0.56634
m3 x 0.1
7.06290 0.70629 0.07063 ----- ----- 2.00000 0.20000 0.02000 0.00200 0.00020
m3 x 1.0
70.62900 7.06290 0.70629 0.07063 ----- 20.00000 2.00000 0.20000 0.02000 0.00200
m3 x 10
----- 70.62900 7.06290 0.70629 0.07063 ----- 20.00000 2.00000 0.20000 0.02000
m3 x 100
----- ----- 70.62900 7.06290 0.70629 ----- ----- 20.00000 2.00000 0.20000
m3 x 1,000
----- ----- ----- 70.62900 7.06290 ----- ----- ----- 20.00000 2.00000
Pulse Output Scaling Factor
(Item 56 & 57)
Form-A type output
Desired Pulse Output Value
Table 6
Form A Pulse Output Scaling
Form-A Configuration Examples:
To configure the Mini-AT
that is programmed for corrected and uncorrected volume in MCF (1000 CuFt)
to output an MCF volume pulses via the two Form-A channels, configure the following items:
Item # Description Value
090 Corrected Volume Units MCF
092 Uncorrected Volume Unite MCF
056 Pulser A Scaling 2.0000
057 Pulser B Scaling 2.0000
093 Pulser A Volume Code CorVol
094 Pulser B Volume Code UncVol
115 Output Pulse Code 0.0625
To configure the Mini-AT
that is programmed for corrected and uncorrected volume in CCF (100 CuFt) to
output a CCF volume pulses via the two Form-A channels, configure the following items:
Item # Description Value
090 Corrected Volume Units CCF
092 Uncorrected Volume Unite CCF
056 Pulser A Scaling 2.0000
057 Pulser B Scaling 2.0000
093 Pulser A Volume Code CorVol
094 Pulser B Volume Code UncVol
115 Output Pulse Code 0.0625
