Mini-AT User Guide
Alarm Pulse Outputs
The Mini-AT
will generate a Form-A, 100 millisecond wide pulse on every new alarm, and if RBX is enabled,
on every alarm automatically cleared. The alarm pulse is available at terminals A- and A+ of TB1 and TB2.
Item Code 108 (Alarms Output) will be logic ‘High’ (1111111
1) to indicate an alarm pulse has been transmit-
ted.
Table 4
Mini-AT Alarm Codes
ALARM DESCRIPTION ITEM # E-CODE
Ver.
6.0206
Ver.
6.1403
Ver.
6.5121
Ver.
6.7010
PULSER A OVER LIMIT 69 .E.0.6.9. X X X X
PULSER B OVER LIMIT 70 .E.0.7.0. X X X X
PULSER C OVER LIMIT 71 .E.0.7.1. X X X X
MAIN BATTERY LOW 99 .E.0.9.9. X X X X
BATT. CYCLES > LIMIT 100 .E.1.0.0. X X X X
MEMORY BATT LOW 101 .E.1.0.1. X X X X
INDEX SW #1 FAULT 102 .E.1.0.2. X X X X
INDEX SW #2 FAULT 103 .E.1.0.3. X X X X
A/D FAULT 104 .E.1.0.4. X X X X
PRESS OUT OF RANGE 105 .E.1.0.5. X X X X
TEMP OUT OF RANGE 106 .E.1.0.6. X X X X
PCOR PRESS LOW 143 .E.1.4.3. X X X X
TEMPERATURE
LOW 144 .E.1.4.4. X X X X
PCOR PRESS HIGH 145 .E.1.4.5. X X X X
TEMPERATURE HIGH 146 .E.1.4.6. X X X X
FLOW RATE HIGH 163 .E.1.6.3. X X X X
RBX ALARM EVENT 176 .E.1.7.6. X X X X
DAILY CORVOL 222 .E.2.2.2. X X X X
PLOG PRESS HIGH 451 .E.4.5.1. X X X
PLOG PRESS LOW 452 .E.4.5.2. X X X
FLOW RATE LOW 461 .E.4.6.1. X
REPLACE MAIN BATT
(""SHUTDOWN"")
.H.E.L.P. .H.E.L.P. X X X X
