Mini-AT User Guide
Item Qty Part # Description
1 1 20-6882 Magnetic Disc Assembly
2 1 20-7283 U.M.B. Assembly
3 1 40-1576 Cap & Chain Assembly
4 1 40-1699-3 Input Switch Board
5 1 40-1728 Cable, Internal RS-232
6 1 40-2041 Transducer Assembly
7 1 40-2335 Mainboard
8 1 40-2112 Pressure Terminator
9 1 20-1009 Clip
10 1 20-1428 Wrench, Bristol
11 1 20-8925 Case, Drilled
12 1 20-8689 Plate, Bent Strike
13 2 20-2191 Vent
14 2 20-3737 Filter
15 2 20-3827 Cable Tie
16 1 20-7289 Plug, Stra
in Relief 5/16 dia
17
18 2 20-7469 Washer, #1/4 Int Lock
19 1 20-8087 Label, Warning DCU Jack
20 1 20-8196 Gasket, RS-232 Case Connector
21 1 20-8204 Washer, #6 Ext Lock
22 2 20-8312 Plug, 1/2 NPT
23 1 20-8911 Fitting, Strain Relief .20-.35
24
25 1 60-1202 Screw, Bd #6-32 x 3/16
26 11 60-1249 Screw, PN #6-32 x 5/16 Self Tap
27 2 60-1247 Screw, Spanner #6-32 x 5/16
28
29 2 60-1607 Nut, Hex #1/4-20
30
Mini-AT Meter Mount Parts List
Item Qty Part # Description
1 1 20-7558 Optional Indexes
2 1 20-8124 Optional Temperature Probes
3 1 20-8513 Adapter Assembly, 1" Union
4 1 20-8911 Fitting, Strain Relief .20-.35
5 1 40-1428 Optional Pressure Transducers
6 1 40-2112 Pressure Terminator Assembly
7 1 40-1962 Dual Index Switch Board Assembly
8 1 40-2061 Remote Switch Interface Board
9 1 40-2063 Single Pulse Alarm Board
10 1 40-2093 High Frequency Input Board
11 1 20-8978 Plate, Cover - 2nd Pressure
12 1 20-8981 Gasket, 2nd Pressure
13 4 60-1322 Screw, Bd #8-32 x 5/8
14 4 60-1605 Nut, Hex #8-32
15
Mini-
AT Meter Mount Options
