Mini-AT User Guide
Item Qty Part # Description
1 1 40-1576 Cap & Chain Assembly
2 1 40-1728 Cable, Internal RS-232
3 1 40-1939 Cable, RSI Board
4 1 40-2016 Remote Switch Interface Board-Mini
5 1 40-2453 Transducer Assembly
6 1 40-2335 Mainboard
7 1 40-2112 Pressure Terminator
8 1
9 2 20-1586 Hangar, Case Top
10 2 20-1587 Hangar, Case Bottom
11 2 20-2191 Vent
12 2 20-3737 Filter
13 4 20-5300 Washer, #10 Ext Lock
14 3 20-7289 Plug, Strain Relief 5/16 dia
15 - 20-7380 Adhesive,
#732 Silicone
1
6 1 20-8087 Label, Warning DCU Jack
17 1 20-8196 Gasket, RS-232 Case Connector
18
19 1 20-8312 Plug, 1/2 NPT
20 1 20-9021 Case, Drilled Mini-AT Wall Mount
21 1 20-8689 Plate, Bent Strike
22 2 20-8911 Fitting, Strain Relief .20-.35
23 1 20-8980 Connector, Case
24
25 1 20-8981 Gasket, Case Connector
26
27 2 20-8159 Washer, #8 Int Tooth Lock
28 4 60-1303 Screw, Fil Hd #8-32 x 3/8
29 10 60-1249 Screw, PN #6-32 x 5/16 Self Tap
30 2 60-1
247 Screw, Spanner #6-32 x 5/16
31 4 60-1353 Screw, Bd Hd #10-32 x 5/16
32
Mini-AT Wall Mount Parts Lis
t
Item Qty Part # Description
1 1 20-8124 Optional Temperature Probes
2 1 20-8912 Fitting, Flex Strain Relief .20-.35
3 1 40-1428 Optional Pressure Transducers
4 1 40-2112 Pressure Terminator Assembly
5 1 40-2063 Single Pulse Alarm Board
6 1 40-2093 High Frequency Input Board
7 1 40-2094 Serial Cable Interface Board
8 1 60-1413 Screw, Fil 1/4 x 3/8
9 1 60-1607 Nut, Hex 1/4-20
10 1 20-7549 Washer, 1/4 Int Lock
11 1 20-8978 Plate, Cover - 2nd Pres
sure
12 1 20-8981 Gasket, 2nd Pressure
13 4 60-1322 Screw, Bd #8-32 x 5/8
14 4 60-1605 Nut, Hex #8-32
15 1 40-1649 Clamp, 3/16 Cable
16 1 60-1202 Screw, Bd #6-32 x 3/16
17 1 20-8204 Washer, #6 Ext Lock
Mini-AT Wall Mount Options
