Page 56
Mini-AT User Guide
Item Number Enable
Item Code 136, Item Number Enable, provides identification of the displayed mag list items. The default
configuration of Mag List 1 and Mag List 2 provides no item identification. When the Item Number Enable feature
is enabled, the meter reader list will include the display of the list's sequence number and the item code number
for the value that will be displayed on the next mag wand input. This feature is available for Mag List 1, Mag List
2 and Live Display items. Although this feature is functionally the same for both mag list 1 and 2 , there is a slight
difference in the display of sequence numbers. Mag List 1 items include a leading zero while Mag List 2 items do
not. Live display items are indicated by the letter ‘L’ and a number. (e.g. L1---008 is Live PCor Gas Pressure)
This difference will allow the user to determine if the LCD is displaying is a Mag List 1, Mag List 2 or Live item.
The Item Number Enable provides eight possible options. Use Mini-AT Link software to select which mag list is
to include the item code identification. The eight options are:
None Live
List 1 List 1, Live
List 2 List 2, Live
List 1 & 2 List 1 & 2, Live
Example #4:
Suppose Display Test, Site ID, Corrected Volume, Uncorrected Volume, Live Gas Pressure, Live Gas
Temperature, Gas Pressure Maximum, Unsquared Super, Battery Voltage and Case Temperature are the only
items desired for the meter reader list. However
item number identification is also desired for both mag lists. The
item code numbers listed below would be configured as follows:
Item Item Legend Selected Description
Code# Item
075 Mag List 2 Item 1 # 009 Gas Pressure Maximum
076 Mag List 2 Item 2 # 047 Unsquared Super
077 Mag List 2 Item 3 # 048 Battery Voltage
078 Mag List 2 Item 4 # 031 Case Temperature
079 Mag List 2 Item 5 # 255 (End-Of-List)
080 Mag List 2 Item 6 # 255 (End-Of-List)
081 Mag List 2 Item 7 # 255 (End-Of-List)
082 Mag List 2 Item 8 # 255 (End-Of-List)
083 Mag List 2 Item 9 # 255 (End-Of-List)
084 Mag List 2 Item 10# 255 (End-Of-List)
085 Mag List 2 Item 11# 255 (End-Of-List)
086 Mag List 2 Item 12# 255 (End-Of-List)
129 Live Display Enable Live PCor &T Live PCor Pressure & Temperature
130 Mag List 1 Item 1 # 061 Display Test
131 Mag List 1 Item 2 # 200 Site ID
132 Mag List 1 Item 3 # 000 Corrected Volume
133 Mag List 1 Item 4 # 002 Uncorrected Volume
134 Mag List 1 Item 5 # 255 (End-Of-List)
135 Mag List 1 Item 6 # 255 (End-Of-List)
136 Item Number Enable List 1 & 2 Item Number Identification for
Mag List 1 and Mag List 2
