Memory Modules
Hardware and Software Guide 9–6
Primary Memory Module Slot
To replace the existing memory module in the primary memory
module slot:
1. Shut down the tablet PC. (If you are not sure whether the
tablet PC is off or in hibernation, turn on the tablet PC by
sliding the power switch toward the front of the tablet PC.
Then shut down the tablet PC through the operating system.)
2. Disconnect all external devices connected to the tablet PC.
3. Disconnect the power cord.
4. Turn the tablet PC upside down.
5. Remove any battery packs from the tablet PC.
6. Remove 11 screws from the bottom of the tablet PC: the four
T8M2.0x18.0 screws 1, the six T8M2.0x9.0 screws 2, and
one T8M2.0x5.0 screw 3.
Ä
The screws in the bottom of the tablet PC are of different
lengths. To protect the tablet PC,
be sure to keep track of the
screws by size and location for safe replacement
.
