Left and right side components
Component Description Function
(1) Key Guard Press to enable Key Guard.
Key Guard will disable buttons and the touchscreen on your HP iPAQ
to avoid any accidental calls.
(2) Volume Up/Down Key Press to increase or decrease the volume.
Press once to temporarily mute the ringtone and notification sounds.
(3) Messaging Press to launch Messaging.
(4) Stylus Use to select elements on the screen and input information.
(5) Micro-USB Connector Use to connect the Micro-USB charging/synchronization cable.
NOTE: Open the protective flap to gain access to the slot.
(6) Stereo Headphone Jack
(2.5 mm)
Use to connect headphones.
NOTE: Open the protective flap to gain access to the slot.
(7) Camera Key Use to launch the camera to capture photos and videos.
Left and right side components 5
