93
Field Description
Reference clock ID
For an IPv4 NTP server:
The field represents the IP address of the remote server when the
local device is synchronized to a remote NTP server.
The field represents the local clock when the local device uses the
local clock as a reference source.
• When the local clock has a stratum level of 1, this field
displays LOCL.
• When the local clock has any other stratum, this field displays
the IP address of the local clock.
For an IPv6 NTP server:
The field represents the MD5 digest of the first 32 bits of the IPv6
address of the remote server when the local device is
synchronized to a remote IPv6 NTP server.
The field represents the local clock when the local device uses the
local clock as a reference source.
• When the local clock has a stratum level of 1, this field
displays LOCL.
• When the local clock has any other stratum, this field displays
the MD5 digest of the first 32 bits of the IPv6 address of the
local clock.
Leap indicator
Alarming status:
• 00—Normal.
• 01—Leap second, indicates that the last minute in a day has
61 s e c o n d s.
• 10—Leap second, indicates that the last minute in a day has
59 seconds.
• 11 —Time is not synchronized.
Clock jitter
Difference between the system clock and reference clock, in
seconds.
Stability
Clock frequency stability. A lower value represents better
stability.
Clock precision Accuracy of the system clock.
Root delay
Roundtrip delay from the local device to the primary reference
source, in milliseconds.
Root dispersion
Maximum error of the system clock relative to the primary
reference source, in milliseconds.
Reference time Reference timestamp.
display ntp-service trace
Use display ntp-service trace to display brief information about each NTP server from the reference
source to the primary reference source.
Syntax
display ntp-service trace [ source interface-type interface-number ]
