Husqvarna TC 85 User Manual

20 TECHNICAL DATA
113
20.1 Engine
Design 1-cylinder 2-stroke engine, water-cooled, with reed
intake and exhaust control
Displacement 84.93 cm³ (5.1828 cu in)
Stroke 48.95 mm (1.9272 in)
Bore 47 mm (1.85 in)
Idle speed 1,400 … 1,500 rpm
Crankshaft bearing 1 grooved ball bearing / 1 roller bearing
Conrod bearing Needle bearing
Piston pin bearing Needle bearing
Pistons Aluminum cast
Piston rings 1 rectangular ring
Engine lubrication Mixture oil lubrication
Primary transmission 20:64 straight cut spur gear drive
Clutch Multidisc clutch in oil bath/hydraulically activated
Transmission 6-gear, claw shifted
Transmission ratio
1st gear 11:29
2nd gear 14:28
3rd gear 16:26
4th gear 19:26
5th gear 21:25
6th gear 20:21
Ignition Kokusan 504
Spark plug NGK BR9 ECMVX
Spark plug electrode gap 0.60 mm (0.0236 in)
Cooling Water-cooled
Starting aid Kick starter
20.2 Engine tightening torques
Screw, adjusting lever M5x16 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, clutch spring retainer M5 6 Nm (4.4 lbf ft)
Screw, control lever M5x12 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, crankshaft position sensor M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, exhaust control bearing
support
M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, exhaust control cap M5 6 Nm (4.4 lbf ft)
Screw, exhaust control cover M5 5 Nm (3.7 lbf ft)
Screw, guide piece M5x12 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, ignition system/stator M5 6 Nm (4.4 lbf ft)
Loctite
®
243™

Husqvarna TC 85 Specifications

General

Starter	Kickstarter
Transmission	6-speed
Engine Type	Single-cylinder, 2-stroke
Displacement	84.9 cc
Clutch	Wet multi-disc
Front Brake	Disc brake
Rear Brake	Disc brake
Front Tire	70/100
Rear Tire	90/100
Wheelbase	1290 mm
Final Drive	Chain
