Husqvarna TC 85 User Manual

11 SERVICE WORK ON THE CHASSIS
53
11.15 Installing the start number plate
A00151-10
– Attach the start number plate to the brake line.
– Position the start number plate.
Holding lugs
1
engage in the fender.
A00150-10
–
Mount and tighten screw
2
.
Guideline
Start number plate
screw
M6 4 Nm (3 lbf ft)
11.16 Removing front fender
Preparatory work
– Remove the start number plate. ( p. 52)
A00138-10
Main work
–
Remove screws
1
.
–
Remove screws
2
. Take off the front fender.

Husqvarna TC 85 Specifications

General

Starter	Kickstarter
Transmission	6-speed
Engine Type	Single-cylinder, 2-stroke
Displacement	84.9 cc
Clutch	Wet multi-disc
Front Brake	Disc brake
Rear Brake	Disc brake
Front Tire	70/100
Rear Tire	90/100
Wheelbase	1290 mm
Final Drive	Chain
