11 SERVICE WORK ON THE CHASSIS
57
11.25 Installing the air filter
V00839-10
Main work
– Mount the clean air filter on the air filter support.
–
Grease the air filter in area
A
.
Long-life grease ( p. 123)
K00988-10
–
Insert the air filter and position top retaining pin
1
in bush-
ing
B
.
The air filter is correctly positioned.
–
Secure the bottom retaining pin
2
with holding tab
C
.
Info
If the air filter is not mounted correctly, dust and dirt
may enter the engine and result in damage.
Finishing work
– Install the air filter box cover. ( p. 56)
11.26 Cleaning the air filter and air filter box
Warning
Environmental hazard Hazardous substances cause environmental damage.
– Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance
with the applicable regulations.
Info
Do not clean the air filter with fuel or petroleum since these substances attack the foam.
Preparatory work
– Remove the air filter box cover. ( p. 55)
– Remove the air filter. ( p. 56)
V00838-01
Main work
– Wash the air filter thoroughly in special cleaning liquid and
allow it to dry properly.
Air filter cleaning agent ( p. 123)
Info
Only squeeze the air filter to dry it; never wring it out.
– Oil the dry air filter with a high quality filter oil.
Oil for foam air filter ( p. 123)
– Clean the air filter box.
– Check the intake flange for damage and looseness.
