Husqvarna TC 85 User Manual

11 SERVICE WORK ON THE CHASSIS
49
A00146-10
–
Remove protective ring
4
.
– Take off the lower triple clamp with the steering stem in a
downward direction.
– Remove the upper steering head bearing.
11.10 Installing the lower triple clamp
V00859-10
Main work
– Clean the bearing and sealing elements, check for damage,
and grease.
High viscosity grease ( p. 123)
– Insert the lower triple clamp with the steering stem. Mount
the upper steering head bearing.
–
Slide on O-ring
1
.
–
Position protective ring
2
.
A00147-10
– Position the upper triple clamp with the handlebar.
–
Mount nut
3
, but do not tighten it yet.

Husqvarna TC 85 Specifications

General

Starter	Kickstarter
Transmission	6-speed
Engine Type	Single-cylinder, 2-stroke
Displacement	84.9 cc
Clutch	Wet multi-disc
Front Brake	Disc brake
Rear Brake	Disc brake
Front Tire	70/100
Rear Tire	90/100
Wheelbase	1290 mm
Final Drive	Chain
