11 SERVICE WORK ON THE CHASSIS
55
Finishing work
– Remove the motorcycle from the lift stand. ( p. 45)
11.20 Removing the seat
K00964-10
–
Remove screw
1
.
– Raise the rear of the seat, pull the seat back, and lift it off.
11.21 Mounting the seat
K00987-01
– Mount the front of the seat on the collar bushing of the fuel
tank, lower the seat at the rear, and push the seat forward.
– Make sure that the seat is correctly locked in.
K00964-10
–
Mount and tighten screw
1
of the seat fixing.
Guideline
Remaining screws,
chassis
M6 10 Nm (7.4 lbf ft)
11.22 Removing the air filter box cover
K00967-10
–
Pull off the air filter box cover sideways in areas
A
,
B
and
C
, and remove toward the front.

Husqvarna TC 85 Specifications

General

Starter	Kickstarter
Transmission	6-speed
Engine Type	Single-cylinder, 2-stroke
Displacement	84.9 cc
Clutch	Wet multi-disc
Front Brake	Disc brake
Rear Brake	Disc brake
Front Tire	70/100
Rear Tire	90/100
Wheelbase	1290 mm
Final Drive	Chain
