20 TECHNICAL DATA
117
20.4 Capacities
20.4.1 Gear oil
Gear oil 0.50 l (0.53 qt.) Engine oil (SAE 10W/40) ( p. 121)
20.4.2 Coolant
Coolant ( p. 121) 0.8 l (0.8 qt.)
20.4.3 Fuel
Fuel tank capacity, approx. 5.2 l (1.37 US gal) Super unleaded (98 octane) mixed
with 2-stroke engine oil (1:40)
( p. 122)
20.5 Chassis
Frame Central tube frame of chrome molybdenum steel tub-
ing, powder-coated
Fork WP Performance Systems Upside down AER 43
Shock absorber WP Performance Systems 4618 PDS DCC
Suspension travel
front 278 mm (10.94 in)
rear 305 mm (12.01 in)
Fork offset 14 mm (0.55 in)
Brake system
front Disc brake with four-pot brake caliper
rear Disc brake with two-pot brake caliper
Brake discs - diameter
front 240 mm (9.45 in)
rear 210 mm (8.27 in)
Brake discs - wear limit
front 3.5 mm (0.138 in)
rear 3.7 mm (0.146 in)
Tire air pressure off road
front 1.0 bar (15 psi)
rear 1.0 bar (15 psi)
Secondary ratio (TC 85 17/14) 13:46
Secondary ratio (TC 85 19/16) 13:49
Chain 1/2 x 5/16”
Rear sprockets available 44, 45, 46, 47, 48, 49, 50, 51
Steering head angle 66°
Wheelbase 1,290±10 mm (50.79±0.39 in)
Seat height, unloaded (TC 85 17/14) 855 mm (33.66 in)
Seat height, unloaded (TC 85 19/16) 890 mm (35.04 in)
Ground clearance, unloaded (TC 85 17/14) 352 mm (13.86 in)
Ground clearance, unloaded (TC 85 19/16) 377 mm (14.84 in)

Husqvarna TC 85 Specifications

General

Starter	Kickstarter
Transmission	6-speed
Engine Type	Single-cylinder, 2-stroke
Displacement	84.9 cc
Clutch	Wet multi-disc
Front Brake	Disc brake
Rear Brake	Disc brake
Front Tire	70/100
Rear Tire	90/100
Wheelbase	1290 mm
Final Drive	Chain
