11 SERVICE WORK ON THE CHASSIS
56
11.23 Installing the air filter box cover
K00966-10
–
Position air filter box cover on collar bushings
1
and
2
and push toward the rear.
–
Engage the air filter box cover in areas
A
,
B
and
C
.
11.24 Removing the air filter
Note
Engine damage Unfiltered intake air has a negative effect on the service life of the engine.
Dust and dirt will enter the engine without an air filter.
– Never start to use the vehicle without an air filter.
Warning
Environmental hazard Hazardous substances cause environmental damage.
– Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance
with the applicable regulations.
Preparatory work
– Remove the air filter box cover. ( p. 55)
K00972-10
Main work
–
Detach retaining tab
1
. Remove air filter with air filter sup-
port.
– Remove air filter from air filter support.
