lsenclosurefanmodule
command
to
display
the
status
of
the
fan
modules.
2.
Press
the
release
tab
on
the
fan
module,
as
Figure
1
18
shows.
3.
Use
the
handle
to
pull
the
fan
module
out
of
the
expansion
enclosure
chassis,
as
shown
in
Figure
1
19
on
page
125.
svc01003
1
Figure
1
17.
Fan
module
LED
svc01030
Figure
1
18.
Fan
module
release
tab
124
SAN
V
olume
Controller:
Model
2145-SV1
Hardware
Installation
Guide
157
159
