Inovance AM600 Series Hardware Manual

-47-
Introduction
Interface Name Function
I/O signal indicator
I/O status indicator:
ON: I/O active
OFF: I/O inactive
24 V power input terminal Module power input
Address switch (rotary
switch)
Sets the slave station address: ADDR1/ADDR0: station address DIP switch. The address is
set in the hexadecimal format. Slave station decimal address = ADDR1 x 16 + ADDR0 x 1
(address range: 1 to 255)
User output terminal For the de󶍾nition
,
see
"Chapter 5 Wiring"
.
3) Module dimensions
57.0
90.0
95.0
0 1 2 3 4 5 6 7
1 2 3 4 5 6 7
X
Y
X1 IN
X2 OUT
X1X16
0V 24V
PWR RUN
SF ERR
AM600-0808ETNE
0
X1
X3
X5
X7
Y0
Y2
Y4
Y6
COM
X0
X2
X4
X6
SS
Y1
Y3
Y5
Y7
57.0
90.0
95
.0
Y0
Y1
Y2
Y3
Y
4
Y5
Y6
Y7
X0
X1
X2
X3
X4
X5
X6
X7
X0
X1
X2
X3
X4
X5
X6
X7
SS0
Y0
Y1
Y2
Y3
Y
4
Y5
Y6
Y7
COM
COM
SS1
0
1 2 3 4
5 6
7
1
2
3 4
5 6
7
1
2 3
4
5 6
7
1 2
3 4
5
6 7
X
X
Y
Y
X1 IN
X2 OUT
X1X16
0V 24V
PWR RUN
SF ERR
AM600-1616ETNE
0
0
0
Figure 3-26 Module installation dimensions (mm)
3.5.3 High-speed Counting Module
A counting module (AM600-2HCE) that supports EtherCAT remote communication is provided. The
speci󶍾cations are as follows:
1) Basic speci󶍾cations
Item Speci󶍾cations
Power supply voltage
24 VDC (20.4 VDC to 28.8 VDC) (–15% to +20%)
,
which can be con-
nected from an external power supply.
Protocol for communication with CPU module EtherCAT
,
100 Mbit/s network speed
EtherCAT communication baud rate
Maximum 100 Mbit/s to support the EtherCAT communication baud
rate of the master station
Network port/network cable
Standard Ethernet port and standard Ethernet cable (Cat5e network
cable)
Station number range
1 to 255. The internal address is automatically arranged in the net-
work bus connection sequence.
