Inovance MD500 User Manual

8 Specifications and Model Selection
-
116
-
8
heated. The K value can be increased appropriately on the condition of good dissipation and should not exceed
50%. Failure to comply may result in a re due to overheating of braking resistor.
Braking frequency (D) is determined by application. Typical values of braking frequency in different applications
are listed in the Table 8-8..
Table 8-8 Typical values of braking frequency in different applications
Application Elevator Winding & Unwinding Centrifuge
Occasional Braking
Load
General Application
Braking
Frequency
20% to 30% 20% to 30% 50% to 60% 5% 10%
8.5.3 Braking Units
Table 8-9 Selection Guidance of Braking Units
MD500 Model
Applicable
Motor
(kW)
Braking Unit
125% Braking Torque
(10% ED, Max. 10s)
Remark
Min.
Resistance
of Braking
Resistor
(Ω)
Model QTY Specication QTY
MD500T0.4GB 0.4
Built-in
80W 1450Ω 1
AC drive model
ending with letter “B”
96
MD500T0.7GB 0.75 140W 800Ω 1 96
MD500T1.1GB 1.1 220W 500Ω 1 96
MD500T1.5GB 1.5 300W 380Ω 1 64
MD500T2.2GB 2.2 440W 260Ω 1 64
MD500T3.0GB 3 600W 190Ω 1 32
MD500T3.7GB 3.7 740W 150Ω 1 32
MD500T5.5GB 5.5 1100W 100Ω 1 32
MD500T7.5GB 7.5 1500W 75Ω 1 32
MD500T11GB 11 2200W 50Ω 1 20
MD500T15GB 15 3000W 38Ω 1 20
MD500T18.5G(B)
(-T)
18.5
Built-in
4000W 32Ω 1 24
MD500T22G(B)
(-T)
22 4500W 27Ω 1 24
MD500T30G(B) 30 6000W 20Ω 1 19.2
MD500T37G(B) 37 7000W 16Ω 1 14.8
MD500T45G(B) 45 9000W 13Ω 1 12.8
MD500T55G(B) 55 11000W 10.5Ω 1 9.6
MD500T75G(B) 75 15000W 7.7Ω 1 6.8
MD500T90G
90 MDBUN-60-T 2 9000W 10.0Ω 2 Input voltage ≤ 440 VAC 9.3 × 2
90 MDBUN-60-5T 2 9000W 12.8Ω 2 Input voltage > 440 VAC 10.5 × 2
MD500T110G
110 MDBUN-60-T 2 11000W 9.4Ω 2 Input voltage ≤ 440 VAC 9.3 × 2
110 MDBUN-60-5T 2 11000W 10.5Ω 2 Input voltage > 440 VAC 10.5 × 2
MD500T132G
132 MDBUN-90-T 2 13000W 6.8Ω 2 Input voltage ≤ 440 VAC 6.2 × 2
132 MDBUN-90-5T 2 13000W 8.8Ω 2 Input voltage > 440 VAC 7.0 × 2
MD500T160G
160 MDBUN-90-T 2 16000W 6.3Ω 2 Input voltage ≤ 440 VAC 6.2 × 2
160 MDBUN-90-5T 2 16000W 7.2Ω 2 Input voltage > 440 VAC 7.0 × 2
