8.7 Applicable Motor
1. A four-pole squirrel-cage asynchronous induction motor is the standard applicable motor. For non-standard
applicable motors, select an AC drive of required rated current.
2. In non-AC drive motors, the cooling fan and rotor shaft are coaxially connected. Cooling effect is reduced
at low speed. A cooling fan with better cooling effect or an AC drive motor must be used to avoid motor
overheating.
3. AC drive provides standard parameters for applicable motors. You can set a value or modify the default
value of the motor according to actual needs; otherwise, the motor running performance or protection may
be affected.
4. Alarm or even motor explosion may occur due to short circuit of cables or the motor. Perform insulation
short circuit test on the motor and cables installed for the rst time and routinely do this test. During the
test, the AC drive must be disconnected from the tested parts.
Table 8-14 Applicable motors
MD500 Model
Power
Capacity
(kVA)
Input Current
(A)
Output
Current
(A)
Applicable Motor
Thermal
Design Power
(kW)
(kW) (HP)
Three-phase, 440 V, 50-60 Hz
MD500T0.4GB 2
1.8 1.5 0.4 0.5 0.039
MD500T0.7GB 2.8 2.4 2.1 0.75 1 0.046
MD500T1.1GB 4.1 3.7 3.1 1.1 1.5 0.057
MD500T1.5GB 5 4.6 3.8 1.5 2 0.068
MD500T2.2GB 6.7
6.3 5.1 2.2 3 0.081
MD500T3.0GB 9.5 9.0 7.2 3 4 0.109
MD500T3.7GB 12 11.4 9.0 3.7 5 0.138
MD500T5.5GB
17.5 16.7 13.0 5.5 7.5 0.201
MD500T7.5GB 22.8 21.9 17.0 7.5 10 0.24
MD500T11GB 33.4 32.2 25.0 11 15 0.355
MD500T15GB 42.8 41.3 32.0 15 20 0.454
MD500T18.5G(B)(-T) 45 49.5 37 18.5 25 0.478
MD500T22G(B)(-T) 54 59 45 22 30 0.551
MD500T30G(B) 52 57 60 30 40 0.694
MD500T37G(B) 63 69 75 37 50 0.815
MD500T45G(B) 81 89 91 45 60 1.01
MD500T55G(B) 97 106 112 55 75 1.21
MD500T75G(B) 127 139 150 75 100 1.57
MD500T90G 150 164 176 90 125 1.81
MD500T110G 179 196 210 110 150 2.14
MD500T132G 220 240 253 132 180 2.85
MD500T160G 263 287 304 160 220 3.56
MD500T200G(-L) 334 365 377 200 275 4.15
MD500T220G(-L) 375 410 426 220 300 4.55
