– 44 –
Belt tension mete
(measurement value)
(28) Adjustment of the tension of the X timing belt
Standard Adjustment
A
B
A
2mm
9.8N
(Example: 2516)
M
W
S
003.4g/m
025 mm/R
0315 mm
TENSION
400.0N
(Example: 2516)
Belt tension meter
(set value)
