– 60 –
4-ø4
37mm
43mm
37mm
3mm
154mm (2516)
96mm (2516)
10mm
3mm
39mm
43mm
4-M6
(38) Making the origin setting gauge
(39) Adjusting the X origin sensor
When the feed is in the mechanical origin, align the tip of the needle with the lateral position of the engraved dot
of the origin.
A
D
C
Standard Adjustment
Standard Adjustment
Origin marking
(for 2516)
B
Y movement base
174mm (3020)
116mm (3020)
Origin marking (for 3020)
