– 46 –
(29) Adjustment of the tension of the Y timing belt
Standard Adjustment
(Example: 2516)
M
W
S
003.4g/m
025 mm/R
0190 mm
TENSION
300.0N
A
B
A
2mm
9.8N
Belt tension mete
(measurement value)
Belt tension meter
(set value)
(Example: 2516)
