– 56 –
(36) Adjustment of the speed controller
Standard adjusting value of the speed controller for the presser cylinder
1. Loosen the nut and once turn the knob fully in Direction A. Then, turn this knob in Direction B by one
turn and tighten the nut .
Standard adjusting value of the speed controller for the 2-step stroke cylinder
1. Loosen the nut and once turn the knob fully in Direction A. Then, turn this knob in Direction B by one
turn and tighten the nut .
Standard Adjustment
For presser cylinder (right)
For presser cylinder (left)
Type L (2-step presser with 2-step stroke)
For 2-step stroke cylinder
For presser cylinder (right)
For presser cylinder (left)
B
A
BA
