Front Panel Operation
2-1
2.1 Introduction
This section contains detailed information for front panel op-
eration of the Model 6517A. It is organized as follows:
2.2 Power-up —
Covers information on connecting the in-
strument to line power, warm-up period, default condi-
tions, and the power-up sequence.
2.3 Display —
Covers display formats, and messages as-
sociated with operation.
2.4 Connections —
Electrometer input and voltage source
output: Provides basic information on the connections
used for typical electrometer and high-resistance meter
measurements. Summarizes guarding and shielding
techniques, and explains the potential hazards present-
ed by floating circuits. Recommends cables and test
fixtures that can be used, and provides guidelines for
building a test fixture.
2.5 Voltage measurements —
Provides the basic proce-
dure to measure voltage. Includes configuration infor-
mation and measurement considerations for the volts
function.
2.6 Current measurements —
Provides the basic proce-
dure to measure current. Includes configuration infor-
mation and measurement considerations for the amps
function.
2.7 Resistance measurements —
Provides the basic pro-
cedures to perform resistance and resistivity measure-
ments. Includes configuration information, the
multiple display and measurement considerations for
the ohms function.
2.8 Charge measurements —
Provides the basic proce-
dure to measure charge. Includes configuration infor-
mation, multiple displays and measurement consider-
ations for the coulombs function.
2.9 Voltage source —
Covers V-source operation includ-
ing how to use the safety interlock.
2.10 Analog outputs —
Provides information needed to
use the 2V analog output and the preamp output.
2.11 Using external feedback —
Explains how to use ex-
ternal feedback to extend the capabilities of the Model
6517A.
2.12 Range and resolution —
Covers both manual and
auto ranging and resolution.
2.13 Zero check and relative —
Provides details on the
zero check and relative (REL) features.
2.14 Test sequences —
Covers the test sequences that can
be configured and run.
2.15 Triggering —
Details types of trigger modes as well as
trigger sources that can be used.
2.16 Buffer —
Covers use of the reading buffer including
programming the buffer size, recalling data and time
stamp.
2.17 Filter —
Covers the use of the digital filter types that
can be used to reduce reading noise.
2.18 Math —
Describes the calculations that can be per-
formed on readings.
2.19 Menu —
Covers selections controlled from the main
menu, such as saving instrument setups, communica-
tion configuration (GPIB and RS-232), and limits.
2.20 Scanning —
Summarizes internal scanning using one
of the optional scanner cards, and explains how to use
the Model 6517A in an external scanning system.
