Kia Stonic User Manual

Maintenance
948
Light bulbs
䳜 If a bulb becomes damaged or
cracked, replace it immediately
and carefully dispose of it.
䳜 Wear eye protection when chang
-
ing a bulb. Allow the bulb to cool
down before handling it.
Position lamp bulb replacement
(Headlamp Type A)
1. Open the bonnet.
2. Remove the headlamp bulb cover
by turning it counterclockwise.
3. Remove the bulb-socket from the
headlamp assembly by turning
the bulb-socket counterclockwise
until the tabs on the bulb-socket
align with the slots on the head
-
lamp assembly.
4. Remove the bulb from bulb-
socket by pulling it out.
5. Insert a new bulb by inserting it
into the bulb-socket.
6. Install the bulb-socket in the
headlamp assembly by aligning
the tabs on the bulb-socket with
the slots in the headlamp assem
-
bly. Push the bulb-socket into the
headlamp assembly and turn the
bulb-socket clockwise.
7. Install the headlamp bulb cover by
turning it clockwise.
Front turn signal lamp bulb
replacement (Headlamp Type A)
1. Open the bonnet.
2. Remove the bulb-socket from the
headlamp assembly by turning
the bulb-socket counterclockwise
until the tabs on the bulb-socket
align with the slots on the head
-
lamp assembly.
3. Remove the bulb from the bulb
socket by pressing it in and rotat
-
ing it counterclockwise until the
tabs on the bulb align with the
slots in the bulb-socket. Pull the
bulb out of the bulb socket.
4. Insert a new bulb by inserting it
into the bulb-socket and rotating
it until it locks into place.
5. Install the socket in the headlamp
assembly by aligning the tabs on
the bulb-socket with the slots in
OYB070050L
OYB070051L
