Kia Stonic User Manual

Maintenance
968
Light bulbs
Static bending light replacement
(Headlamp Type B)
1. Open the bonnet.
2. Remove the headlamp bulb cover
by turning it counterclockwise.
3. Disconnect the static bending
light bulb socket-connector.
4. Unsnap the static bending light
bulb retaining wire by pressing
the end and pushing it upward.
5. Remove the bulb from the head
lamp assembly.
6. Install a new static bending light
bulb and snap the static bending
light bulb retaining wire into posi
-
tion by aligning the wire with the
groove on the bulb.
7. Connect the static bending light
bulb socket-connector.
8. Install the headlamp bulb cover by
turning it clockwise.
Front turn signal lamp bulb
replacement (Headlamp Type B)
1. Open the bonnet.
2. Remove the headlamp bulb cover
by turning it counterclockwise.
3. Remove the bulb-socket from the
headlamp assembly by turning
the bulb-socket counterclockwise
until the tabs on the bulb-socket
align with the slots on the head
-
lamp assembly.
4. Remove the bulb from the bulb
socket by pressing it in and rotat
-
ing it counterclockwise until the
tabs on the bulb align with the
slots in the bulb-socket. Pull the
bulb out of the bulb-socket.
5. Insert a new bulb by inserting it
into the bulb-socket and rotating
it until it locks into place.
6. Install the socket in the headlamp
assembly by aligning the tabs on
the bulb-socket with the slots in
the assembly. Push the bulb-sock
et into the headlamp assembly
and turn the socket clockwise.
OYB070053L
OYB070054L
