INTRODUCTION
0-8
WB140-
2N,
WB150-
2N
TRANSMISSION SERIAL NUMBER
The serial number for
the transmission is stamped o
n a plate located on
the right side o
f the transmission
case.
CAB SERIAL NUMBER
The serial number for
the cab is stamped on a p
late located on the right
center pillar
.
CANOPY SERIAL NUMBER
The serial number for
the canopy is stamped on the plate located on the
inside u
pper righ
t corner
.
11
13
