SPECIFICATIONS
4-2 WB140-2N, WB150-2N
TECHNICAL DATA
STANDARD OVERALL DIMENSIONS
Pos. WB140-2N
Standard
WB140-2N
Telescopic Arm
WB150-2N
Standard
WB150-2N
Telescopic Arm
A 2175 mm (7’ 2”) 2175 mm (7’ 2”) 2175 mm (7’ 2”) 2175 mm (7’ 2”)
B 2080 mm (6’ 10”) 2080 mm (6’ 10”) 2080 mm (6’ 10”) 2080 mm (6’ 10”)
C 2945 mm (9’ 8”) 2940 mm (9’ 8”) 3015 mm (9’ 8”) 2940 mm (9’ 8”)
D 7200 mm (23’ 7”) 7195 mm (23’ 7”) 7270 mm (23’ 10”) 7195 mm (23’ 7”)
E 3625 mm (11’ 11”) 3630 mm (11’ 11”) 3625 mm (11’ 11”) 3630 mm (11’ 11”)
F 2750 mm (9’ 0”) 2750 mm (9’ 0”) 2750 mm (9’ 0”) 2750 mm (9’ 0”)
G 2320 mm (7’ 8”) 2320 mm (7’ 8”) 2320 mm (7’ 8”) 2320 mm (7’ 8”)
H 3780 mm (12’ 4”) 3780 mm (12’ 4”) 3780 mm (12’ 4”) 3780 mm (12’ 4”)
