OPERATION
2-18 WB140-2N, WB150-2N
GEAR SHIFT LEVER CONTROLS
The gear shift lever (1) is used to change travel speed ranges. it is
equipped with a declutching button (2) which is used to disengage the
drive line for changing speed ranges.
DECLUTCH BUTTON
To change speed ranges, slow the machine down, press the declutch but-
ton (2) and shift to the desired speed range, release the declutch button
as quick as possible.
CHANGING SPEED RANGES
The machine is equipped with four speed ranges. The lower speed
ranges are for using the front end loader or slow maneuvering on a job
site. The higher ranges are for forward ground or road travel.
DIRECTIONAL CONTROL LEVER
When operating in a desired speed range shown above you can choose a
forward or reverse direction by simply using the directional control
lever (1). This function allows you to change direction quickly and eas-
ily without using any type of clutching mechanism.
To operate, lift the lever and move it into any direction:
F
- Forward travel.
N
- Neutral.
R
- Reverse travel.
Remark
The machine can only be started in the (N) neutral position. When parking the machine, shift into the (N) posi-
tion and set the parking brake for safety. Avoid changing direction when traveling at fast speeds, always slow
down and apply the brakes before changing direction.
• Engage the gears only with the engine running at a low
RPM and the machine is traveling slowly or stopped.
• Avoid up-shifting when using the machine in heavy oper-
ations.
• Always shift the lever into a neutral position (N) when
parking the machine and set the parking brake.
3rd. and 4th. speed ranges are for forward operation only. Do
not travel in reverse using the 3rd. or 4th. speed range. Loss
of control may result.
