OPERATION
2-16 WB140-2N, WB150-2N
FRONT END LOADER CONTROLS
LOADER DECLUTCH CONTROL BUTTON
This button (1) allows the operator the option of transferring all engine
power from the drive line to the loader hydraulics when lifting heavy
loads.This feature should only be used on level ground.
DIFFERENTIAL LOCK BUTTON
This button (2) allows the operator the option of locking the drive
wheels together when operating in 1st. 2nd. or 3rd. gear. It is used when
there is wheel spinning or when loading the bucket in slippery locations.
Remark
This function does not work in 4th. gear range. Before engaging this feature be sure the machine is stopped or
traveling at a slow speed.
1 Loader declutch control button
2 Differential lock button
3 Bucket open button
4 Bucket close button
5 Front end loader speed control button
• Do not use this button for more than 15 to 20 seconds.
• Do not use this button when traveling or operating on an
incline. Loss of control may result.
Do not use this feature when traveling on slopes. To engage
the differential lock feature, the system must disengage the
drive line first. Loss of control may result.
