OPERATION
2-4 WB140-2N, WB150-2N
PICTOGRAMS
The pictographs applied to the machine are there to alert the operator or maintenance personnel of system functions and possi-
ble dangers associated with the system. It is important for the operator or maintenance personnel to understand what these pic-
tographs mean. It is also important to replace these pictographs if they become damaged or are missing. Below are a list of the
pictographs equipped with your machine and there meanings.
WORK AREA DANGERS
Do not allow personnel to approach the machine when the front end
loader is in operation. Always maintain a clearance of 12m (40 ft.) away
from any personnel any time the machine is in operating.
MOVING OR ROTATING ENGINE COMPONENTS
Always keep clear of rotating or moving parts especially in the engine compartment.
FILLING THE HYDRAULIC SYSTEM
This is only for machines using biodegradable oil. (Type HEES)
ENGINE OIL FILTER
BRAKE FLUID
