OPTIONAL ATTACHMENTS
WB140-2N, WB150-2N 5-21
CONNECTING AND REMOVING THE JACK HAMMER
CONNECTING THE JACK HAMMER
To connect the hammer, proceed as follows:
1. Stop engine and neutralize all hydraulic controls to relieve any pressure on the system.
2. Turn ignition switch to the “I” position and press switch (4) to release any residual pressure from the hammer.
3. Make sure couplings are clean and free from dirt or debris. Carefully install the couplings.
4. Turn switch (4) off and start the engine.
5. Engage switch (4) and increase engine RPM to required setting in the tool operation manual.
DISCONNECTING THE JACK HAMMER
To disconnect the hammer, proceed as follows:
1. Press button (4) to disengage solenoid and shut the hydraulics down.
2. Stop engine and neutralize all hydraulic controls to relieve any pressure on the system.
3. Turn ignition switch to the “I” position and press switch (4) to release any residual pressure from the hammer.
4. Turn switch off.
5. Disconnect the tool and cap all connection openings.
USING THE JACK HAMMER
For operation of jack hammer, see manual provided with the tool.
Connection and removal of the hammer must be carried out with machine in the parked position, parking
brake set, and all safety locks engaged.
