KTM 450 Rally Replica User Manual

CONTROLS 19
601307-10
• F FRONT – If the tap handle  of the fuel tap points toward the rear, fuel is taken
from the two front fuel tanks. Only the front fuel tanks empty out completely.
601308-10
• R REAR – If tap handle  of the fuel tap points up, fuel is taken from the rear fuel
tank. Only the rear fuel tank empties out completely.
4.31Choke
601293-10
The choke lever  is fitted on the left side of the handlebar.
Activating the choke function frees an opening through which the engine can draw
extra fuel. This gives a richer fuel-air mixture, which is needed for a cold start.
Info
If the engine is warm, the choke function must be deactivated.
Possible states
• Choke function activated – The choke lever is pulled to the stop.
• Choke function deactivated – The choke lever is pushed back to the stop.
4.32Shift lever
601288-11
The shift lever  is mounted on the left side of the engine.
601288-12
The gear positions can be seen in the photograph.
The neutral or idle position is between the first and second gears.

KTM 450 Rally Replica Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	449.3 cc
Cooling	Liquid cooled
Fuel System	Keihin EFI, throttle body 44 mm
Transmission	6-speed
Starter	Electric starter
Bore x Stroke	95 mm x 63.4 mm
Compression Ratio	12.75:1
ABS	No
Seat Height	960 mm
Dry Weight	139 kg
Frame	Chromoly steel central-tube frame
Front Suspension	WP XACT PRO 48 mm, closed cartridge
Rear Suspension	WP XACT PRO with Trax technology
Front Brake	300 mm
Rear Brake	Single disc, 240 mm
