KTM 450 Rally Replica User Manual

CONTROLS 20
4.33Foot brake lever
601309-10
Foot brake lever  is located in front of the right footrest.
The rear brake is engaged with the foot brake lever.
4.34Side stand
601318-10
The side stand  is on the left side of the vehicle.
600012-10
The side stand is used to park the motorcycle.
Info
When you are riding, the side stand  must be folded up and secured with the
rubber band .
4.35Steering lock
601300-10
The steering lock  is fitted on the left of the steering head.
The steering lock is used to lock the steering. Steering, and therefore riding, is no
longer possible.
4.36Locking the steering
Note
Danger of damage The parked vehicle may roll away or fall over.
– Always place the vehicle on a firm and even surface.
400732-01
– Park the vehicle.
– Turn the handlebar as far as possible to the right.
– Insert the key in the steering lock, turn it to the left, press it in, and turn it to the
right. Remove the key.
Steering is no longer possible.
Info
Never leave the key in the steering lock.

KTM 450 Rally Replica Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	449.3 cc
Cooling	Liquid cooled
Fuel System	Keihin EFI, throttle body 44 mm
Transmission	6-speed
Starter	Electric starter
Bore x Stroke	95 mm x 63.4 mm
Compression Ratio	12.75:1
ABS	No
Seat Height	960 mm
Dry Weight	139 kg
Frame	Chromoly steel central-tube frame
Front Suspension	WP XACT PRO 48 mm, closed cartridge
Rear Suspension	WP XACT PRO with Trax technology
Front Brake	300 mm
Rear Brake	Single disc, 240 mm
