SERVICE WORK ON THE CHASSIS 44
9.14Removing the seat
601347-10
– Lift and turn quick release bracket .
– Pull on loop . At the same time, lift the seat at the rear and take it off.
9.15Mounting the seat
601348-10
– Let the locking pin of the seat engage in lock housing .
– Lock the seat at the front with quick release .
– Make sure that the seat is correctly locked in.
9.16Removing the air filter x
– Remove the seat. ( p. 44)
601349-10
– Remove screws . Take off air filter box lid .
