MAINTENANCE ON CHASSIS AND ENGINE 101
100093-10
– Push the upper chain section at the end of the chain sliding component upwards to
measure the chain tension .
Info
The lower chain section must be taut.
Chain wear is not always even, so you should repeat this measurement at differ-
ent chain positions.
Chain tension 140… 145 mm (5.51… 5.71 in)
» If the chain tension does not meet specifications:
– Adjust the chain tension. ( p. 103)
9.25Checking rear sprocket / engine sprocket for wear
400227-01
– Check rear sprocket / engine sprocket for wear.
» If the rear sprocket / engine sprocket are worn:
– Replace the rear sprocket / engine sprocket.
Info
When fitting the chain joint, always make sure that the closed side of the
joint faces forward (riding direction).
The engine sprocket, rear sprocket and chain should always be replaced
together.
– Check that the chain guides are tight.
