MAINTENANCE ON CHASSIS AND ENGINE 133
100091-10
– The main fuse is located in the starter relay in front of the battery.
– Remove protection covers .
– Remove the faulty main fuse.
Info
You can recognize a blown fuse by its broken filament .
Warning
Fire hazard The electrical system can be overloaded by the use of incorrect
fuses.
– Use only fuses with the prescribed amperage. Never by-pass or repair fuses.
– Insert the new fuse.
Fuse (58011109120)
Tip
Replacement fuse should always be present in the starter relay to make sure
it is available when needed.
– Replace the protection covers.
9.54Changing the fuses of individual power consumers
– Remove the front cover. ( p. 140)
– Switch off all power consumers and switch off the engine.
