MAINTENANCE ON CHASSIS AND ENGINE 113
100072-10
– Insert the inside brake lining into the brake caliper and fix with bolt .
– Insert the external brake lining into the brake caliper and slide the bolts in all the way.
100073-10
– Mount the locking split pins .
– Operate the hand brake lever repeatedly until the brake linings lie on the brake disc and
there is a pressure point.
– Mount the wheel/wheels. ( p. 126)
9.37Changing the front brake linings x
Warning
Skin irritation Brake fluid can cause skin irritation on contact.
– Avoid contact with skin and eyes, and keep out of the reach of children.
– Wear suitable protective clothing and goggles.
– If brake fluid gets into your eyes, rinse thoroughly with water and contact a doctor immediately.
