MAINTENANCE ON CHASSIS AND ENGINE 105
9.28Greasing the rear wheel eccentric element
601052-10
– Use a grease gun to fill the rear wheel eccentric element via the grease nipple until
grease emerges from the left shaft seal ring .
Long-life grease ( p. 198)
9.29Checking brake discs
Warning
Danger of accidents Reduced braking efficiency due to worn brake disc(s).
– Change the worn brake disc(s) without delay. (Your authorized KTM workshop will be glad to help.)
400362-10
– Check the thickness of the front and rear brake discs at several places on the disc to
see if it conforms to measurement .
Info
Wear reduces the thickness of the brake disc around the area used by the brake
linings.
Brake discs - wear limit
Front 3.5 mm (0.138 in)
Rear 3.5 mm (0.138 in)
