MAINTENA
NCE
ON
CHASSIS
AND
ENGINE
142
9.64
Installing
the
front
trim
601064-10
–
Connect
the
plug-in
connectors
of
the
head
light
and
the
emergency
OFF
switch
with
the
rip
cord
and
position
the
front
trim.
–
Mount
all
screws.
–
Fully
tighten
screws
.
Guideline
Screw
on
fuel
tank
M6
6
Nm
(4.4
lbf
ft)
–
Fully
tighten
screws
.
Guideline
Remaining
screws,
chassis
M6
10
Nm
(7.4
lbf
ft)
–
Install
the
front
cover.
(
p.
140)
9.65
Removing
the
rear
fender
–
Remove
the
seat
(
p.
136)
143
145
