MAINTENANCE ON CHASSIS AND ENGINE 121
9.43Removing rear brake linings x
Warning
Danger of accident Brake system failure.
– Maintenance work and repairs must be carried out professionally. (Your authorized KTM workshop will be glad to help.)
601054-01
– Press the brake caliper by hand on to the brake disc in order to press back the brake
piston.
601055-10
– Loosen the screw while holding the hexagonal head of the bearing bolt. Unscrew
the screw by approx. 10 turns and use the screw to press the bearing bolt out of the
brake caliper. Remove screw.
